WAGO - 289-445

Interface module - stand-alone PCB with mounting feet - WAGO (289 series) - 9-poles (9P) - with 9-pin D-sub male connector (system; vertical connection) + 2-row spring CAGE CLAMP 9-pin for 0.08...2.5mm2 cables (field) - Rated current 1A - DIN-35 rail mounting (38mm width) - rated for -20°C...+50°C ambient - equivalent to 289445

Specifications

• Primary brand: WAGO
• Functions: Interface module
• Design: stand-alone PCB with mounting feet
• Poles: 9-poles (9P)
• Rated current: 1A
• Rated Voltage (DC): 50Vdc
• Rated voltage (AC): 30Vac
• Connection type: 9-pin D-sub male connector (system; vertical connection)|2-row spring CAGE CLAMP 9-pin for 0.08...2.5mm2 cables (field)
• Mounting mode: DIN-35 rail
• Dimensions: H63.5mm x W38mm x D19mm
• Net Width (mm): 38mm
• Ambient air temperature for operation: -20°C...+50°C
• Ambient air temperature for storage: -40°C...+70°C
• Humidity: ≤85% relative humidity (RH; non-condensing)
• GTIN code: 4045454367107
• Customs Tariff Number: 85366990990
• eClass code: 27-14-11-52
• ETIM code: EC002780
• Order code / Manufacturer SKU: 289-445
• Manufacturer product status: Commercialized
• Equivalent to: 289445
• EAN code: 4045454367107
• Compliant with standard(s): EN 61010-2-201|RoHS compliant with exemption (6(c))
• Location of origin: Germany
• Degree of pollution: 2
• Level 1 category: Automation components
• Product title: Interface module - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85366990990
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-14-11-52
• eCl@ss 9.0: 27-14-11-52
• ETIM 8.0: EC002780
• ETIM 9.0: EC002780
• GTIN: 4045454367107
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 25 (1) pcs

Connection data

• Connection 1 - Connection type 1: System
• Connection 1 - Mating direction: vertical
• Connection 1 - Note (conductor cross-section): 12 AWG: THHN, THWN
• Connection 1 - Pluggable connector: D-subminiature male connector
• Connection 1 - Pole number 1: 9
• Connection 2 - Connection technology: CAGE CLAMP^®
• Connection 2 - Connection type: Field
• Connection 2 - Design 2: PCB terminal blocks (double-row)
• Connection 2 - Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Connection 2 - Pole number 2: 9
• Connection 2 - Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Connection 2 - Strip length: 5 … 6 mm / 0.2 … 0.24 inches
• Connection 2 - WAGO connector 2: WAGO 236 Series
• Performance level: 2 / 200 mating cycles
• Strain relief: UNC 4-40 stud bolt

Electrical data

• Contact resistance (max.): 30 mΩ
• Nominal current: 1A
• Operating voltage: ≤ 30 VAC; ≤ 50 VDC

Environmental Product Compliance

• CAS-No.: 7439-92-1
• REACH Candidate List Substance: Lead
• RoHS Compliance Status: Compliant,With Exemption
• RoHS Exemption: 6(c)
• SCIP notification number (Austria): f6f34124-5997-4bb6-88cb-79a4ea0d10c1
• SCIP notification number (Belgium): dc3fac1c-474a-433e-9cd1-9f7975dfe386
• SCIP notification number (Bulgaria): 8425726f-12d2-41d2-9a80-1cc6b1e5f065
• SCIP notification number (Czech Republic): 340c1a7e-0ebb-4888-b6f5-bf608ed6087d
• SCIP notification number (Denmark): c49092f0-5d30-4da8-9899-aa4a424a7211
• SCIP notification number (Finland): 008676ad-47b0-422c-adb2-3577ac7e7a96
• SCIP notification number (France): 235af48a-fad9-4e4b-aaeb-70f2e2e6e263
• SCIP notification number (Germany): 242f2721-9f4e-42c8-8906-3342d83893dd
• SCIP notification number (Hungary): 611c15b2-4a1a-437f-86e4-00ba7f72c599
• SCIP notification number (Italy): 9574028a-336b-4d6d-a799-9bda0cef6376
• SCIP notification number (Netherlands): f1ab783c-f94a-4563-8e8f-6cb329511767
• SCIP notification number (Poland): 018b6a92-3b87-4572-8e3b-75ba6f269d35
• SCIP notification number (Romania): c7b81add-4814-496d-9a18-5a9c6295321f
• SCIP notification number (Sweden): f4611b51-97c4-428b-a913-efd74126e58c

Environmental requirements

• Ambient temperature (operation): -20 … +50 °C
• Ambient temperature (storage): -40 … +70 °C
• Relative humidity: ≤ 85 % (non-condensing)

Material data

• Contact material (connector): Au over Ni
• Fire load: 0.056MJ
• Weight: 24.7g

Mechanical data

• Housing design: PCB with mounting feet
• Mounting type: DIN-35 rail

Physical data

• Depth from upper-edge of DIN-rail: 19 mm / 0.748 inches
• Height: 63.5 mm / 2.5 inches
• Width: 38 mm / 1.496 inches

Safety and protection

• Insulation type: Basic insulation
• Pollution degree: 2
• Protection type: IP00
• Rated impulse withstand voltage: 0.8kV
• Rated voltage: 50V

Standards and specifications

• Standards/specifications: EN 61010-2-201
